Green House Gas Analysis
Green House Gas Analysis
Greenhouse gases are those that are found in the atmosphere that induce the greenhouse effect, which is an absorbance and emission of infrared energy emitted by the Earth. As sunlight strikes the surface of the Earth, some of the infrared light is reflected into the atmosphere. These greenhouse gases absorb that infrared energy and reflect it toward the Earth. This gas chromatograph system enables the easy qualitative and quantitative analysis of three major greenhouse gases: methane(CH4), carbon dioxide(CO2), and nitrous oxide(N2O).
Green House Gas Analyzer Lineup
Model Name | Conventional GHC system | NARO x Shimadzu System1 | Jetanizer-FID & ECD System |
---|---|---|---|
Features |
・Conventional GHG analysis |
・High throughput analysis |
・High throughput analysis |
Selection Guide |
・Small number of samples |
・Large number of samples |
・Large number of samples |
GC model | GC-2014 | GC-2014 | GC-2030 |
Analysis time / GC cycle time |
12/14 min |
7/9 min (Isothermal) |
3/5 min (Isothermal) |
Area repeatability | 0.5%RSD | 0.5%RSD | 1%RSD |
Detector |
Methanizer FID |
FID |
Jetanizer FID |
LOD |
CH4: 1ppm CO2: 1ppm N2O: 0.05ppm |
CH4: 0.1ppm CO2: 100ppm N2O: 0.05ppm |
CH4: 0.4ppm CO2: 0.4ppm N2O: 0.1ppm |
Column | Packed column | Packed column | Capillary column |
Notes: National Agriculture and Food Research Organization.
This system was developed in collaboration with Dr. Shigeto Sudo at NARO.
Caution: Available systems vary by region.
Common Items
GC Type | Applicated GC/Analyzer |
---|---|
Sampling technique | Sampling bag or on-line sampling with gas sampling valve injection Vial sampling with syringe injection by autosampler |
Carrier gas | N2 |
Detector gas |
FID; Air、H2、N2 |
