Standard samples, tubes, etc.

Add Bookmark

Last update: May 9, 2022 GMT

Drain tube, nebulizer gas tube
Name P/N Qty Remarks Applicable model Links Applicable models
PVC tube for waste liquid
016-31414
1m For waste liquid from the spray section
LCMS-9030
LCMS-8060
LCMS-8050
LCMS-2020
9030
8060
8050
8030
8040
2020
2010
Silicone rubber tube for waste liquid
016-31350-19
1m For waste liquid from the waste tray
LCMS-8060
LCMS-8050
LCMS-2020
8060
8050
8030
8040
2020
2010
Standard sample
Name P/N Qty Remarks Applicable model Links Applicable models
Standard sample for autotuning
225-34260-01
400mL Nal (sodium iodide)
LCMS-9030
9030
Standard sample for autotuning
225-14124-01
200mL PEG (polyethylene glycol), raffinose 8080
Standard sample for autotuning
225-14122-01
200mL PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose
LCMS-8060
LCMS-8050
8060
8050
8030
8040
Standard sample for autotuning
225-14985-01
200mL PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose
LCMS-2020
2020
Standard sample for autotuning
225-06613-06
200mL PEG (polyethylene glycol), raffinose 2010
Rotary pump oil
Name P/N Qty Remarks Applicable model Links Applicable models
Rotary pump oil  LV0700
225-27850-02
1L 2 L per use
LCMS-9030
LCMS-8060
9030
8060
Rotary pump oil  GS495
017-30168-01
1L 8080
Rotary pump oil  Ultragrade#19
017-30163-02
4L 1.5 L per use except 8080
except 8060
Sample delivery unit (for LCMS-8080)
Name P/N Qty Remarks Applicable models
PEEK tube
228-33833-91
3m Inner diameter: 0.13 mm LCMS-8080
PEEK coupling
228-25014
1 LCMS-8080
PEEK nut
228-18565-84
5 LCMS-8080
Syringe for autotuning
225-25043-41
5mL Inner diameter: 10.30 mm LCMS-8080
Tee joint
225-25031-10
1 LCMS-8080
Tube cutter
225-25031-08
1 LCMS-8080
Straight joint
225-25031-07
1 LCMS-8080
Syringe for infusion analysis
225-25031-02
1mL Inner diameter: 4.61 mm LCMS-8080
PTFE tube
228-18495-01
1m Cut the tube into 20 to 30 mm length pieces before use. LCMS-8080
Standard sample introduction unit (for LCMS-2010)
Name P/N Appearance Qty Remarks Applicable models
Reflex fitting set
228-45407-92
Set of 5 Used for pipe connection from the 6-port valve to the ESI/APCI probe LCMS-2010
Plunger assembly
228-25237-17
1 5mL LCMS-2010
Microsyringe1005C
228-25237-07
228-25237-07 1 LCMS-2010
